Cyre P
CYRE P is the wall mounted version of the CYRE luminaire. Based on an cylindric extruded aluminium profile and a faceted reflector made in high reflection polycarbonate.
Technical characteristics
| Installation | Wall |
| Color | White | Black |
| CRI | > 80 |
| IP | 20 |
| Range power (W) | 6 - 6 |
| Color temperature (ºK) | 3000 | 4000 |
| Light range | 760 - 885 |
| Dali option |
|
Downloads
References
Use the filters to see the model reference of this product that best fits your project:
| Reference | NG Calc | Version | Gross lumen output | Power | Temperature | IP | Downloads |
|---|---|---|---|---|---|---|---|
| AC03B |
|
Standard | 760 | 6,4 | 3000 | 20 |
|
| AC03N |
|
Standard | 760 | 6,4 | 3000 | 20 |
|
| AC03UB |
|
Standard | 760 | 6,4 | 3000 | 20 |
|
| AC04B |
|
Standard | 885 | 6,4 | 4000 | 20 |
|
| AC04N |
|
Standard | 885 | 6,4 | 4000 | 20 |
|
| AC04UB |
|
Standard | 885 | 6,4 | 4000 | 20 |
|
| AC03DB |
|
DALI 1 | 760 | 6,4 | 3000 | 20 |
|
| AC03DN |
|
DALI 1 | 760 | 6,4 | 3000 | 20 |
|
| AC04DB |
|
DALI 1 | 885 | 6,4 | 4000 | 20 |
|
| AC04DN |
|
DALI 1 | 885 | 6,4 | 4000 | 20 |
|
* Net Lumen output is indicated in technical datasheet.
